Mazak VCN 510C Centre d’Usinage Usagé 2008 – 3201071

---

Fraiseuse CNC / Centre d’usinage

Year

2008

Travel

X-Axis Stroke.............................. 41.3"

Y-Axis Stroke.............................. 20.0"

Z-Axis Stroke.............................. 20.0"

Size

Comments

Table Size................................. 51.1" x 21.6"

X-Axis Stroke.............................. 41.3"

Y-Axis Stroke.............................. 20.0"

Z-Axis Stroke.............................. 20.0"

Spindle Face to Table Surface(Min/Max)..... 5.91"/25.98"

Maximum Table Weight Capacity.............. 2,646 LBS

Spindle Speed.............................. 12,000 RPM

Spindle Motor (5MIN/10MIN/30MIN/CONT.)..... 25/20/15/10.2 HP

Spindle Taper ............................. #40

Rapid Traverse (X,Y,Z)..................... 1417.3 IPM

Number of Tools............................ 30

Maximum Tool Diameter...................... 3.15"

Maximum Tool Diameter (Adjacent Pockets)... 4.92"

Maximum Tool Length........................ 13.78"

Maximum Tool Weight........................ 17.64 LBS.

Tool Select Method......................... RANDOM

Tool Change Time (Chip to Chip)........ 2.9 SEC (1,000 RPM)

........ 5.8 SEC (12,000 RPM)

Power Supply (5 MIN/CONT).................. 41.6/25.9 Kva

Air Supply................................. 72.52"

Machine Height............................. 111.93"

Floor Space................................ 113.3" X 111.6"

Machine Weight............................. 14,616 LBS

---

Price request
